Whether you’re ripping fast flowy singletrack, putting the power down on punchy climbs, or tearing the tires off in the corners, the Optic continues to push the boundaries of what’s possible on a short travel trail bike.
| FRAME | Carbon Frame, 125mm Travel, UDH, Eagle Transmission Compatible, Ride Aligned™ |
| FORK | Fox 36 or Fox 34 Performance Elite Float, GripX, HSC/LSC/HSRT/ LSR, 140mm, 44mm Offset, Fender Included |
| REAR SHOCK | Fox Float X2 Performance Elite, 185x50mm TR |
| HEADSET | FSA No. 57 ZS, Sealed Bearing, Tapered 1-1/8" - 1.5", ( ZS44/28.6 | ZS56/40 ) |
| GRIPS | Ergon GE1, Slim (S1, S2) Standard (S3,S4,S5) |
| HANDLE BAR | OneUp Aluminum, 800mm, 35mm rise |
| STEM | OneUp 42mm Length, 35mm clamp |
| SEAT POST | TranzX YS105, 34.9mm, 150 (S1) -170mm (S2) -200mm (S3,S4) -230mm (S5) |
| SADDLE | Ergon SM-1 Enduro |
| FRONT BRAKE | SRAM Maven Silver, Metalllic Pads |
| FRONT BRAKE ROTOR | SRAM Centerline, 200mm, 1.8mm Thickness, 6 bolt |
| REAR BRAKE | SRAM Maven Silver, Metalllic Pads |
| REAR BRAKE ROTOR | SRAM Centerline, 180mm, 1.8mm Thickness, 6 bolt |
| BRAKE LEVERS | Sram Maven Silver |
| SHIFTER REAR | SRAM Pod Controller, MMX Bridge |
| REAR DERAILLEUR | SRAM S1000 Eagle AXS T-Type, 12sp |
| CASSETTE | SRAM 1270 Eagle T-Type, 10-52T, 12sp |
| CHAIN | SRAM GX Eagle T-Type, 12sp |
| CRANKSET | Sram Eagle 90, 32T, CL55, 165mm (S1,S2) -170mm (S3,S4,S5) |
| BOTTOM BRACKET | SRAM DUB, BSA 73mm, MTB WIDE |
| FRONT HUB | Sram MTH 716, 15x110 Boost,32H, 6-bolt |
| REAR HUB | Sram MTH 746, 12x148mm Boost, XD, 32H, 6-bolt |
| SPOKES/NIPPLES | Sapim Race butted 2.0/1.8/2.0,14G, stainless steel |
| RIMS | Stan’s Flow S2, 32H, F- 29", R-27,5", 30mm ID |
| FRONT TIRE | Maxxis Minion DHF, 3C Max Terra EXO , 29x2.5", Folding |
| REAR TIRE | Maxxis Minion DHRII, 3C Max Terra EXO , 27.5x2.4", Folding |
