The smallest range of certified cams in the DMM stable.

Description

DMM Dragonfly Cams are the world's smallest micro cams available. The CNC machined head provides maximum strength and durability in a tiny package, and with the DMM Triad technology you can rest assured that your cams will be reliable every time.

The size 1 Dragonfly is our smallest certified climbing cam. The six cams in the range cover placements from 7.8mm – 28.3mm.

The same camming angle of 13.75°, as used with our Dragons, provides the optimum balance of holding power and range. You will appreciate the holding power of the TripleGrip lobes with their ‘raw alu’ surface, particularly on smooth rock types such as slate and limestone. The narrow head width and compact trigger allow the cams to be placed deep in small pockets.

Features

Features intro / description

Optional Paragraph left column

• 13.75° camming angle
  Optimum combination of holding power and range.
• TripleGrip lobes with ‘raw alu’ surface
  Increases coefficient of friction meaning cam is more likely to hold on smooth rock types. TripleGrip gives greater surface texture interaction and makes the cam less likely to walk and perform better in flared cracks.
• Flexible stem cable
  Minimises walking
• Narrow head width
  Helps with small pocket placements
• Compact trigger bar
  Allows deep placements
• Extendable 11mm Dynatec sling with compact stitch pattern
  Extend either strand and save using a quickdraw
• Complement smaller Dragon Cams
  Sizes 4, 5, and 6 Dragonfly Cams overlap with size 00 – 1 Dragons

Sizing

- click the link for sizing chart.

DragonFly Size

Colour

Weight

Range

Dragon 1

Green

55g

7.8-11mm

Dragon 2

Red

56g

8.7-12.9mm

Dragon 3

Gold

65g

10.2-15.2mm

Dragon 4

Blue

67g

12.1-17.9mm

Dragon 5

Silver

70g

15.1-22.5mm

Dragon 6

Purple

73g

19-28.3mm
